Main Features
1、 Gigabit PON port for uplink and downlink, high bandwidth and low delay requirements.
2、 1x10/100/1000M Ethernet electrical port is used to connect lower-level terminals to form an all-optical network. It is used to connect lower-level terminals for FTTR and FTTO.
3、Support GPON.
4、 Support packet filtering and protection against illegitimate packet attacks, suppressing unknown unicast, broadcast, and multicast messages .
5、 Support PPPoE+ function for accurate user identification.
6、Support multicast protocols such as IGMP Snooping/MLD.
7、PON system downstream uses AES-128 algorithm for data encryption.
8、 Support dual management mode based on DBA technology or priority to ensure the minimum specified bandwidth requirements of users.
|
Specification |
Features |
Function Description |
|
PON uplink port
|
Working wavelength |
Transmit wavelength: 1310nm Receiving wavelength: 1490nm |
|
Output optical power |
-1～+4dBm |
|
|
Receiving sensitivity |
<-28dBm |
|
|
Connector |
SC/PC Connector |
|
|
UNI User interface |
1x10/100/1000M Ethernet electrical port |
Support 10/100/1000M adaptive |
|
Network management mode |
Local management |
Support local WEB management |
|
Remote management |
Centralized management on OLT, support WEB, CLI |
|
|
Software upgrade |
Local upgrade |
Local download and upgrade via WEB |
|
Remote upgrade |
Remote software download and upgrade through the OLT CLI |
|
|
Physical properties |
Size |
88x81x25mm (length * width * height) |
|
Power supply |
DC 12V 0.5A |
|
|
Power consumption |
〈6W |
|
|
Environmental parameters |
Operating temperature：-10～45℃ Storage temperature：-30～60℃ Relative humidity：10～90% (non condensing) |
|
|
Weight |
90g |
