1GE+3FE+1TEL+2USB+WIFI(2.4G&5G)
Category: FTTH ONU
Model: GPB650
Spec:1GE+3FE+1TEL+2USB+WIFI(2.4G&5G)(compatible EPON/GPON)
Consult Now
Description
Features
Specifications
1、 Gigabit
PON port for uplink and downlink, high bandwidth and low delay requirements.
2、 1GE+3FE
Ethernet electrical port is used to connect lower-level terminals to form an
all-optical network. It is used to connect lower-level terminals for FTTR and
FTTO.
3、Provide
1 RJ11 telephone port, support SIP voice and fax.
4、Support
2.4G/5G dual-band WIFI.
5、Support
EPON/GPON dual-mode adaptive.
6、 Supports
packet filtering and protection against illegitimate packet attacks,
suppressing unknown unicast, broadcast, and multicast
messages .
7、 Support
PPPoE+ function for accurate user identification.
8、Support
multicast protocols such as IGMP Snooping/MLD.
9、 PON
system downstream uses AES-128 algorithm for data encryption.
10、 Support
dual management mode based on DBA technology or priority to ensure the minimum
specified bandwidth requirements of users.
|
Specification
|
Features
|
Function Description
|
|
PON uplink port
|
Working wavelength
|
Transmit wavelength: 1310nm
Receiving wavelength: 1490nm
|
|
Output optical power
|
-1～+4dBm
|
|
Receiving sensitivity
|
<-28dBm
|
|
Connector
|
SC/PC Connector
|
|
UNI User interface
|
1GE+3FE Ethernet electrical port
|
Support 10/100/1000M adaptive
|
|
Telephone interface
|
1 RJ11 interface
|
Support SIP
|
|
WIFI interface
|
2.4G/5G dual-band 2 antenna or 4 antenna
|
Support 802.1a/g/n/ac
|
|
USB interface
|
2
|
Support USB 2.0
|
|
Network management mode
|
Local management
|
Support local WEB management
|
|
Remote management
|
Centralized management on OLT, support WEB, CLI
|
|
Software upgrade
|
Local upgrade
|
Local download and upgrade via WEB
|
|
Remote upgrade
|
Remote software download and upgrade through the OLT CLI
|
|
Physical properties
|
Size
|
194x152×32mm (length * width * height)
|
|
Power supply
|
DC 12V 1A
|
|
Power consumption
|
〈12W
|
|
Environmental parameters
|
Operating temperature：-10～45℃
Storage temperature：-30～60℃
Relative humidity：10～90% (non condensing)
|
|
Weight
|
311g
|
