Hardware

CPU&Memery

Powerful dual-core 1.0GHz processor

Memory: 2Gbits flash and 4Gbits RAM

Interfaces

4(or 5) 10/100/1000 Mbps Gigabit Ethernet ports

--- WAN & LAN

1 USB3.0 port

Buttons

Power On/Off

Reset

Wi-Fi On/Off

WPS

LEDs

PWR,WAN, LAN1,LAN2,LAN3,LAN4,USB,WLAN,WPS

Antenna

4 external antennas (7dB)

Wi-Fi 6

WiFi 6 (802.11ax) dual band WiFi

Frequency: 2.4 GHz, 5GHz

EasyMesh support

Up to 2100Mbps

IEEE 802.11a/n/ac/ax Wi-Fi @5GHz 2 x 2，MU-MIMO

IEEE 802.11b/g/n Wi-Fi @2.4GHz 2 x 2，MU-MIMO

WPA/WPA2/ WPA3 Security

Up to four broadcast/hidden SSIDs for each band

USB

1*USB3.0 port（optional）

Software

Networking

Easymesh Support

IPv4/IPv6 Dual Stack

SNTP client

NAT/ALG

Static routing/Dynamic routing

PPPoE client/passthrough

DNS client/relay

DHCP client/server

IGMP and MLD snooping/proxy

QoS

Flexible packet classification

Up to eight queues

SP/WRR/SP+WRR

Ingress rate limit

Egress shaping

WMM(Wi-Fi Multi Media)

Security

Based on uni port, VLAN ID, 802.1p, uni + 802.1p or VLAN + 802.1p

Denial of service attack defense

Multiple VPN (IPSec, PPTP) pass through

MAC address filtering

Broadcast / unicast / multicast attack defense

Broadcast packet rate limit

Dual impression for automatic firmware rollback

Support port MAC address limit

Support port protection

Support data encryption

Support status detection and fault reporting

Standards-based WiFi Security (802.11i,128-bit AES encryption with PSK)

Support WPA3, the latest and cuttingedge WiFi security protocol

Management

TR-069/remote management

WEB GUI management

Local built-in diagnostic function

Logs and statistics

Remote upgrade by HTTP

Multicast

Support IGMP snooping

Support MLD snooping
