GPB550
Category: GPON ONU
CPU:RTL9603-VF-CG
DDR:1Gb
FLASH:1Gb
Ethernet Interface:10/100/1000M Base-T port (RJ45) *1, 10/100M Base-T port (RJ45) *1
POTS Interface:4-core phone port (RJ11) *1
Consult Now
  • Description
  • Features
  • Hardware Specifications
  • Specifications

      Main Features

      1、 Gigabit PON port for uplink and downlink, high bandwidth and low delay requirements.

      2、 1GE+3FE Ethernet electrical port is used to connect lower-level terminals to form an all-optical network. It is used to connect lower-level terminals for FTTR and FTTO.

      3、Provide 1 RJ11 telephone port, support SIP voice and fax.

      4、Support 2.4G WIFI.

      5、Support EPON/GPON dual-mode adaptive.

      6、Supports packet filtering and protection against illegitimate packet attacks, suppressing unknown unicast, broadcast, and multicast messages .

      7、 Support PPPoE+ function for accurate user identification.

      8、Support multicast protocols such as IGMP Snooping/MLD.

      9、PON system downstream uses AES-128 algorithm for data encryption.

      10、Support dual management mode based on DBA technology or priority to ensure the minimum specified bandwidth requirements of users.


      Product Specification

      Specification

      Features

      Function Description

      PON uplink port

      Working wavelength

      Transmit wavelength: 1310nm
      Receiving wavelength: 1490nm

      Output optical power

      -1+4dBm

      Receiving sensitivity

      <-28dBm

      Connector

      SC/PC Connector

      UNI User interface

      1GE+3FE Ethernet electrical port

      Support 10/100/1000M adaptive

      Telephone interface

      1 RJ11 interface

      Support SIP

      WIFI interface

      2.4G band

      Support 802.1a/g/n

      USB interface

      1

      Support USB2.0

      Network management mode

      Local management

      Support local WEB management

      Remote management

      Centralized management on OLT, support WEB, CLI

      Software upgrade

      Local upgrade

      Local download and upgrade via WEB

      Remote upgrade

      Remote software download and upgrade through the OLT CLI

      Physical properties

      Size

      150x115x35mm (length * width * height)

      Power supply

      DC 12V 1A

      Power consumption

      9W

      Environmental parameters

      Operating temperature: -1045

      Storage temperature: -3060

      Relative humidity: 1090% (non condensing)

      Weight

      226g
